Roti & Dough
Automatic Roti Pressing Machine – Eco Series
Compact automatic roti press in two Eco models, CP 300 Eco and CP 500 Eco, rated 300 and 500 roti per hour.
- Models Available
- 2
- Category
- Roti & Dough
- Applications
- 3
At a Glance
Compact automatic roti press in two Eco models, CP 300 Eco and CP 500 Eco, rated 300 and 500 roti per hour.
- Best suited for
- Caterers, Hotels, Restaurants, Temples & Community Kitchens
- Available models
- 2 models — CP 300 Eco, CP 500 Eco
Overview
About the Automatic Roti Pressing Machine – Eco Series
The ATHAK Automatic Roti Pressing Machine Eco Series presses roti rounds from dough balls. Two models are listed on page 14 of the catalogue: the CP 300 Eco, rated 300 ROTI per hour with a 5mm*8 inch ceramic coating plate, a 25W impulse motor and a 230V single phase (1800W) supply; and the CP 500 Eco, rated 500 ROTI per hour with a 5mm*9 inch ceramic coating plate, a 40W impulse motor and a 230V single phase (2300W) supply. Listed weights are 18 KG and 25 KG, and roti size and thickness ranges are 2-6 inch and 2-7 inch respectively, both at 1-3mm.
Specifications
Available Models & Technical Specifications
Every model of the Automatic Roti Pressing Machine – Eco Series, with specifications as printed in the ATHAK product catalogue.
The Automatic Roti Pressing Machine – Eco Series is available in 2 models:
- CP 300 Eco
- CP 500 Eco
| Specification | CP 300 Eco | CP 500 Eco |
|---|---|---|
| CAPACITY | 300 ROTI (PER HOUR) | 500 ROTI (PER HOUR) |
| SIZE | 13*9*12 feet | 15*14*18 feet |
| WEIGHT | 18 KG | 25 KG |
| PLATE SIZE & TYPE | 5mm*8 inch Ceramic Coating | 5mm*9 inch Ceramic Coating |
| ROTI SIZE & THICKNESS | 2-6 inch & 1-3mm | 2-7 inch & 1-3mm |
| POWER SUPPLY & LOAD | 230V single phase (1800W) | 230V single phase (2300W) |
| POWER CONSUMPTION | 1.2unit | 1.5unit |
| MOTOR | 25W impulse motor | 40W impulse motor |
Specification notes
- SIZE is printed as "13*9*12 feet" for the CP 300 Eco and "15*14*18 feet" for the CP 500 Eco. Those figures are hard to reconcile with the listed weights of 18 KG and 25 KG and with the photographs of a benchtop machine, so the printed unit "feet" needs confirming with ATHAK. The values are reproduced exactly as printed and this product is flagged verificationRequired for that reason.
- POWER CONSUMPTION is printed without a space as "1.2unit" and "1.5unit", and the catalogue does not state the period the unit figure covers; both are reproduced exactly as printed.
- PLATE SIZE & TYPE is printed with a space before "inch" on this page ("5mm*8 inch Ceramic Coating") where the PRO series tables print it closed up ("14mm*10inch Ceramic Coating"); each is reproduced as printed.
- Model names are printed as "CP 300 Eco" and "CP 500 Eco" on page 14 but as "CP300 Eco" and "CP500 Eco" in the page 3 index; the page 14 spelling is used here.
- Page 14 prints a separate specification table for each model rather than one model-per-column table; both tables carry the same eight labels in the same order.
- The Eco Series qualifier is taken from the catalogue's own page 14 section heading, "Roti Making Machine Eco Series (Regular)", printed directly above the "Automatic Roti Pressing Machine" heading.
Some details for this machine are pending final verification against the source catalogue. Confirm exact specifications when requesting a quote.
Applications
What It's Used For
- Automatic pressing of roti and chapati rounds from dough balls
- Compact roti pressing where floor space is limited
- Roti pressing ahead of a separate bhatti or tawa for roasting
Industries Served
Who Uses This Machine
Features
Key Features
- Two models listed: CP 300 Eco and CP 500 Eco
- Rated capacities of 300 and 500 ROTI per hour
- Ceramic coating plates of 5mm*8 inch and 5mm*9 inch
- 25W and 40W impulse motors
- Both models run on 230V single phase, at 1800W and 2300W
- Listed weights of 18 KG and 25 KG
Related Machinery
You May Also Need
Automatic Roti Making Machine (Pressing + Roasting) – Eco Series
Eco series automatic roti machine pressing and roasting in one pass, in four models rated 300 to 1000 roti per hour.
Automatic Press Machine CP-1000 Pro
Automatic roti press rated 1000 ROTI per hour, with a 14mm*10inch ceramic coated plate and 120W impulse motor.
Hand Press Machine
Hand-operated roti press rated 500 ROTI per hour, with a 12mm*10inch ceramic coated plate and heavy duty pressing frame.
Chapati Bhatti
Heavy top-plate gas bhatti for roasting chapati at speed, in four models from 18*36*12 to 24*48*32.
Flour (Dough) Kneading Machine – SS Body
Full stainless steel body atta kneader in six models from 2 KG to 25 KG, for hygienic, low-maintenance operation.
FAQ
Automatic Roti Pressing Machine – Eco Series Questions
How many models of the Automatic Roti Pressing Machine – Eco Series are available?
The Automatic Roti Pressing Machine – Eco Series is available in 2 models: CP 300 Eco, CP 500 Eco. Full specifications for each model are listed on this page.
What is the production capacity of the Automatic Roti Pressing Machine – Eco Series?
Rated capacity varies by model, as printed in the ATHAK product catalogue: 300 ROTI (PER HOUR), 500 ROTI (PER HOUR).
What motor power is available on the Automatic Roti Pressing Machine – Eco Series?
Motor power across the available models, as printed in the ATHAK product catalogue: 230V single phase (1800W), 1.2unit, 25W impulse motor, 230V single phase (2300W), 1.5unit, 40W impulse motor.
Which Automatic Roti Pressing Machine – Eco Series model is right for my requirement?
Share your production volume and requirement when you request a quote. ATHAK will confirm which model fits and what is possible for your specific case.
How do I get a price quote for the Automatic Roti Pressing Machine – Eco Series?
Share the model you need — or your production requirement — through the quote request form, by phone, or on WhatsApp, and ATHAK will respond with pricing for the right model.
