Automatic Roti Making Machine (Pressing + Roasting) – PRO Series
Automatic roti machine pressing and roasting in one pass, in four PRO models rated 500, 700, 1000 and 2000 roti per hour.
- Models Available
- 4
- Category
- Roti & Dough
- Applications
- 4
At a Glance
Automatic roti machine pressing and roasting in one pass, in four PRO models rated 500, 700, 1000 and 2000 roti per hour. Available in 4 models, from 500 ROTI (PER HOUR) (S 500 Pro) to 2000 ROTI (PER HOUR) (S 2000 Pro).
- Best suited for
- Caterers, Hotels, Restaurants, Industrial Kitchens, Temples & Community Kitchens
- Available models
- 4 models — S 500 Pro, S 700 Pro, S 1000 Pro, S 2000 Pro
- Production capacity
- 500 ROTI (PER HOUR) to 2000 ROTI (PER HOUR)
Overview
About the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series
The ATHAK Automatic Roti Making Machine PRO Series presses and roasts roti in a single machine. Four models are listed on page 13 of the catalogue — S 500 Pro, S 700 Pro, S 1000 Pro and S 2000 Pro — rated at 500, 700, 1000 and 2000 ROTI per hour. All four carry a 14mm*10inch ceramic coating plate, an SS304 three-layer conveyor, SKF bearings and a roti size and thickness range of 2-8 inch and 1-3mm, with gas consumption listed at 1-1.5 KG per Hour. The three smaller models run on 230V single phase (2500W, 3500W and 4500W); the S 2000 Pro is listed at 415V 3 phase (4KW per phase). Listed weights run from 225 KG to 600 KG and burner counts from 5 Nos to 12 Nos.
Specifications
Available Models & Technical Specifications
Every model of the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series, with specifications as printed in the ATHAK product catalogue.
The Automatic Roti Making Machine (Pressing + Roasting) – PRO Series is available in 4 models:
- S 500 Pro
- S 700 Pro
- S 1000 Pro
- S 2000 Pro
| Specification | S 500 Pro | S 700 Pro | S 1000 Pro | S 2000 Pro |
|---|---|---|---|---|
| CAPACITY | 500 ROTI (PER HOUR) | 700 ROTI (PER HOUR) | 1000 ROTI (PER HOUR) | 2000 ROTI (PER HOUR) |
| CAPACITY | 4*2.5*5 feet | 5*3*5 feet | 6*3*5 feet | 6*4*5 feet |
| WEIGHT | 225 KG | 350 KG | 450 KG | 600 KG |
| PLATE SIZE & TYPE | 14mm*10inch Ceramic Coating | 14mm*10inch Ceramic Coating | 14mm*10inch Ceramic Coating | 14mm*10inch Ceramic Coating |
| ROTI SIZE & THICKNESS | 2-8 inch & 1-3mm | 2-8 inch & 1-3mm | 2-8 inch & 1-3mm | 2-8 inch & 1-3mm |
| POWER SUPPLY & LOAD | 230V single phase (2500W) | 230V single phase (3500W) | 230V single phase (4500W) | 415V 3 phase (4KW per phase) |
| POWER CONSUMPTION | 2 unit | 2.5 unit | 3 unit | 6 unit |
| MOTOR | 0.5 hp godrej or V-guard | 0.5 hp godrej or V-guard | 0.5 hp godrej or V-guard | 0.5 hp godrej or V-guard |
| GAS CONSUMPTION | 1-1.5 KG per Hour | 1-1.5 KG per Hour | 1-1.5 KG per Hour | 1-1.5 KG per Hour |
| CONVEYOR | SS304 (3 layer) | SS304 (3 layer) | SS304 (3 layer) | SS304 (3 layer) |
| BURNER | 5 Nos | 5 Nos | 6 Nos | 12 Nos |
| BEARINGS | SKF | SKF | SKF | SKF |
Specification notes
- The catalogue prints two consecutive rows both labelled CAPACITY. The first carries the roti-per-hour rating; the second carries the machine's overall dimensions in feet. Both labels are reproduced exactly as printed.
- The page 13 table has no column header naming the models. The four columns are matched to the four models by their roti-per-hour ratings (500, 700, 1000 and 2000), which correspond directly to the model names S 500 Pro, S 700 Pro, S 1000 Pro and S 2000 Pro printed beside the table, and follow the same order as the page 3 index.
- Model names are printed as "S 500 Pro", "S 700 Pro", "S 1000 Pro" and "S 2000 Pro" on page 13 but as "S500 Pro", "S700 Pro", "S1000 Pro" and "S2000 Pro" in the page 3 index; the page 13 spelling is used here.
- POWER CONSUMPTION is printed as a bare "unit" figure (2 unit, 2.5 unit, 3 unit, 6 unit); the catalogue does not state the period the unit figure covers.
- MOTOR is printed as "0.5 hp godrej or V-guard" with lower-case "hp" and "godrej"; it is reproduced exactly as printed.
- The page 13 heading reads "Automatic Roti Making Machine (Pressing + Roasting)" with no series qualifier. The PRO Series qualifier is taken from the catalogue's own section heading on page 12, "Roti Making Machine PRO Series (Heavy Duty)", under which the page 3 index groups these four models.
Applications
What It's Used For
- Automatic roti and chapati making with pressing and roasting in one pass
- Continuous roti production from dough balls to roasted roti
- Bulk roti output for large-batch meal service
- Roti production lines running on gas burners
Industries Served
Who Uses This Machine
Features
Key Features
- Four models listed: S 500 Pro, S 700 Pro, S 1000 Pro and S 2000 Pro
- Rated capacities of 500, 700, 1000 and 2000 ROTI per hour
- Pressing and roasting in one machine, over an SS304 three-layer conveyor
- 14mm*10inch ceramic coating plate on all four models
- Burner counts of 5, 5, 6 and 12 Nos, with gas consumption listed at 1-1.5 KG per Hour
- 230V single phase supply on the S 500, S 700 and S 1000 Pro; 415V 3 phase on the S 2000 Pro
- SKF bearings and a 0.5 hp godrej or V-guard motor across the range
Related Machinery
You May Also Need
Automatic Roti Making Machine (Pressing + Roasting) – Eco Series
Eco series automatic roti machine pressing and roasting in one pass, in four models rated 300 to 1000 roti per hour.
Automatic Press Machine CP-1000 Pro
Automatic roti press rated 1000 ROTI per hour, with a 14mm*10inch ceramic coated plate and 120W impulse motor.
Chapati Bhatti
Heavy top-plate gas bhatti for roasting chapati at speed, in four models from 18*36*12 to 24*48*32.
Drum Type Dough Kneading Machine
Enclosed drum kneader for dust-free, uniform dough, in five models from 7 KG to 50 KG batch size.
Dough Ball Cutting Machine (Electric)
Electric dough ball cutter portioning 1000-2500 pieces per hour at 20g to 50g ball size, on a 0.5 HP motor.
FAQ
Automatic Roti Making Machine (Pressing + Roasting) – PRO Series Questions
How many models of the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series are available?
The Automatic Roti Making Machine (Pressing + Roasting) – PRO Series is available in 4 models: S 500 Pro, S 700 Pro, S 1000 Pro, S 2000 Pro. Full specifications for each model are listed on this page.
What is the production capacity of the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series?
Rated capacity varies by model, as printed in the ATHAK product catalogue: 500 ROTI (PER HOUR), 4*2.5*5 feet, 700 ROTI (PER HOUR), 5*3*5 feet, 1000 ROTI (PER HOUR), 6*3*5 feet, 2000 ROTI (PER HOUR), 6*4*5 feet.
What motor power is available on the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series?
Motor power across the available models, as printed in the ATHAK product catalogue: 230V single phase (2500W), 2 unit, 0.5 hp godrej or V-guard, 230V single phase (3500W), 2.5 unit, 230V single phase (4500W), 3 unit, 415V 3 phase (4KW per phase), 6 unit.
Which Automatic Roti Making Machine (Pressing + Roasting) – PRO Series model is right for my requirement?
Share your production volume and requirement when you request a quote. ATHAK will confirm which model fits and what is possible for your specific case.
How do I get a price quote for the Automatic Roti Making Machine (Pressing + Roasting) – PRO Series?
Share the model you need — or your production requirement — through the quote request form, by phone, or on WhatsApp, and ATHAK will respond with pricing for the right model.
